Report item
Item specifics
  • is_customized: Yes Eddystone Compatible bluetooth ibeacon sticker NRF51822
  • Model Number: W917N Bluetooth iBeacon
  • Size: 73*36*36mm
  • Main chip: NRF51822
  • System: IOS 5.0, Android 4.3 or above
  • Battery: ER26500-9500mAH
  • Battery Life: 10 years
  • Working range: 70m
  • Certificate: CE FCC RoHS ibeacon
  • Work voltage: 2.0-3.6V
  • name: Eddystone Compatible bluetooth ibeacon sticker NRF51822
Product Description
                                               Welcome to our iBeacon Beacon Store
W917N w917n



Product Description





Features:



- Built-in Beacon firmware
- Built-in a coin battery
- Bluetooth low energy technology compatible
- Excellent link budget (up to 97dB)
- Enable long range applications
- Accurate digital RSSI
- Apple&MFI Certified and compatible with CE and FCC regulation
- High performance and low power 8051 core MCU
- Temperature sensor
- AES security coprocessor





IBeacon Descriptions:

Run standalone as iBeacon, External host is not required.
Based on NRF51822Chip.




  • Run standalone as iBeacon, External host is not required.
  • Application for advertisement and location.
  • Built in pairing password to prevent others to modify the settings .
  • Support customize your own iBeacon configuration including UUID etc.
  • Tx Power configurable.
  • Advertising frequecy configurable.
  • Support upgrade firmware through OAD (air upgrade) .
  • Built in JTAG port for customized other application firmware as a standalone system.

Item

Value

Remarks

Firmware

iBeacon

Version 1.3.1

Battery model

ER26500

ER26500-9500mAH, 1pc

Operation Frequency

2400-2483.5MHz

Programmable

Frequency Error

+/- 20KHz



Modulation

Q-QPSK



Standby current

100uA

Depends on duty cycle/broadcasting frequency

Broadcasting Frequency

900mS

Duty cycle

Output Power

0 dBm

Default setting, programmable

Receiving Sensitivity

-93dBm

High gain mode

Transmission distance

70 meters

BER<0.1%, Open space

Antenna

50ohm

On board/ PCB Antenna

Size

73*36*36mm



Operation Voltage

2.0-3.6V

DC



Packaging & Shipping



1.Original Package and Standard Package
2.Shipping 2-3 working days after the payment confirmed.
3.It will be shipped by DHL/FedEx /TNT/ UPS /EMS or other special way. Please contact with us and choose the best one.



Our Services

Refund & Replacement:



1. One month for return policy from the arrival date.
2. Please simply return to us for replacement or refund, when you find the unperfected quality items or they don’t work well.
3. If the items are defective please notify us within 3 days after arrival.
4. Any items must be returned in their original condition to get a refund or replacement




Other Policies:



1. About MOQ which depends on your order.
2. About warranty we give one month for refund or replacement.
3. About sample which needs your charge.
4. About inventory which changes everyday and depends on your order.
5. About order process: We will send you a PI (term of shipping, aggregate amount and so on) after receive you parts list.



We also take OEM,ODM orders as your design, if you have any question, feel free to contact us.

Packaging Details
  • Unit Type: lot (2 pieces/lot)
  • Package Weight: 0.1kg (0.22lb.)
  • Package Size: 8cm x 8cm x 6cm (3.15in x 3.15in x 2.36in)
